The Method Of Improving The Filling Quality Of Capsule Filling Machine

The Method Of Improving The Filling Quality Of Capsule Filling Machine

The filling quality of capsule filling machine is very important, which has become a very concerned problem of pharmaceutical companies, so the capsule machine needs to constantly improve the equipment, optimize the automatic capsule filling machine structure, help pharmaceutical companies better production.

In addition to the quality of the automatic capsule machine itself, the capsule filling machine environment, transportation process, and each station will affect the filling quality. Users need to pay special attention to several stations of the equipment when operating the hard capsule filling machine, including the following parts.

First, automatic hard capsule filling machine capsule u-turn and separation station. This position is the capsule feeding and separation mechanism, the purpose is to put the capsule into the module and separate the capsule body and capsule cap for the next drug filling.

Automatic capsule machine the common problems include bad separation, flying cap, etc., the pressure adjustment for vacuum separation should be appropriate, not too large or too small, too large flying cap phenomenon, too small will make the separation of bad phenomenon, at the same time, the capsule must be purchased from the regular manufacturer, and passed the inspection.

Second, automatic capsule filling machine filling station. This station mainly controls the filling weight of the capsule contents, and the main common problem is that the weight of the filling contents is unstable.

The reasons mainly include three aspects: first, the measuring plate of automatic hard capsule filling machine is not well aligned with the lower module, so that the weight of some finished capsules is always too light. The problem here is not easy to find, the user assembly before production, debugging capsule filling machine here must do a good job; Second, the gap between the isolation block on the metering plate and the metering plate is too large, which makes the drug flow into the metering hole through the gap during filling, resulting in a large weight of the capsule. Generally, it is better to adjust the gap between the isolation block and the metering plate between 0.05~0.1mm. If it is too small, it will wear and tear the metering plate and damage the equipment.
