Automatic Capsule Filling Machine Metering Plate

Automatic Capsule Filling Machine Metering Plate

The bottom of the metering disc of the automatic capsule filling machine is embedded with an inlet sealing device, which improves the leakage of medicinal powder. The lower bracket is passivated with imported aviation aluminum, which does not generate static electricity, does not stick to powder, and is easy to clean; Improve the structure of the powder scraper: change the traditional flat angle scraping powder It can make the filling volume at the beginning and end of each station of the metering plate consistent with other holes, and improve the filling accuracy of the powder; the intelligent module of the man-machine interface configuration adopts the German original Siemens software, and has complete monitoring functions. Operational faults such as feed channel blockage and mechanical failure have realized automatic diagnosis and monitoring, automatic alarm and stop. Statistical preparation of production date, production time, real-time per-grain measurement and cumulative output is correct.

The automatic capsule filling machine avoids cross-contamination and saves energy: redesigns the discharging mechanism of the finished capsules, eliminating the need for an air compressor, thereby reducing the overall size and noise of the whole machine, avoiding cross-contamination and movement failures caused by air-pressure discharging, and Remarkable energy-saving effect has been achieved; The automatic capsule filling machine is convenient to adjust the gap of the dose disc, only need to adjust the angle of the gear mandrel, it can drive the transmission gear, so that the 5 supporting bolts can be raised or lowered at the same time; in view of the different characteristics of Chinese and Western medicine, The running pressure required for filling is large, the size of the cam is increased, and the surface of the cam is treated with nitrogen to increase the surface hardness and ensure the service life and operation reliability of the equipment.
