Maintenance of Vacuum Separator of Fully Automatic Capsule Filling Machine

Maintenance of Vacuum Separator of Fully Automatic Capsule Filling Machine

The vacuum separator of the vacuum system of the automatic capsule filling machine mainly plays the role of sucking the capsule into the upper and lower modules and separating the cap and the body during the filling of the hard capsule. If the capsule cannot be separated from the cap and the body, the subsequent filling will not be carried out. Each time the turntable of the automatic capsule filling machine rotates a station, the main shaft of the machine rotates once, and the vacuum separator of the automatic capsule filling machine moves up and down once under the action of the cam.

If the cap and body of the capsule are not separated smoothly, check the gap between the upper plane of the vacuum separator and the lower plane of the lower module. If the gap is too large, the vacuum degree of the vacuum system cannot reach the vacuum degree required for the separation of the cap and body. If the gap is too small, it is easy to cause a collision to deform the lower module. When the position of the vacuum separator needs to be adjusted, use the handle to turn the main motor shaft of the automatic capsule filling machine to raise the vacuum separator to the highest position, loosen the lock nuts at both ends of the adjustment rod under the machine table, and then rotate the adjustment rod Adjust the height of the vacuum separator, then tighten the nut, and use the handle to rotate the main motor shaft to test until it is suitable. The vacuum degree is read on the vacuum gauge on the operation panel of the machine. When the vacuum is too high, the vacuum degree regulating valve can be opened appropriately, and when the vacuum is too low, the vacuum degree regulating valve can be closed or closed. The filter of the vacuum system of the automatic capsule filling machine should be opened regularly to clean up the clogged dirt to ensure that the vacuum system has sufficient vacuum.
