Vacuum Separator Maintenance Of Automatic Capsule Filling Machine

Vacuum separator maintenance of automatic capsule filling machine

The vacuum separator of the vacuum system of the automatic capsule filling machine mainly plays a role in the filling of hard capsules by inhaling the capsules into upper and lower modules and separating the cap and body. If the capsules cannot be separated from the cap and body, the subsequent filling will not be carried out. The rotary table of the automatic capsule filling machine runs every station, the main shaft of the machine rotates for a week, and the vacuum separator of the automatic capsule filling machine moves up and down once under the action of the CAM.

If the separation of capsule cap and body is not smooth, check the gap between the upper plane of the vacuum separator and the lower plane of the lower module. If the gap is too large, the vacuum degree of the vacuum system cannot reach the vacuum degree required by the separation of the cap and body. If the gap is too small, it is easy to cause headbutt and deform the lower module. When need to adjust the position of the vacuum separator, with rotates fully automatic capsule filling machine Lord motor shaft, to rise to make the vacuum separator zui high position, loosen the machine adjust lock nut at the ends of the rod under the table, then turn adjusting screw to adjust the height of the vacuum separator, then lock nut and turn the main motor shaft test by the handle until it is right. The vacuum degree is read on the vacuum table on the machine operation panel. When the vacuum degree is too high, the vacuum degree regulating valve can be properly opened. When the vacuum degree is too low, the vacuum degree regulating valve can be turned down or closed. The filter of vacuum system of automatic capsule filling machine should be opened regularly to clean up the blocked dirt, so as to ensure that the vacuum system has enough vacuum degree.
