How To Install The Tablet Press Machine Mold

How To Install The Tablet Press Machine Mold

The use of tablet press, mold plays a very important role, directly affect the weight difference and hardness of tablets, so the installation must be correct, the method is as follows:

A, rotary tablet press mold before installation, should be burst disc in the working face, upper and lower die, die, die in top silk, oil ring, plate, copper ring, and the size of the powder scraper, guide, cover plate, dust cover, out of the mouth, feeding boots, transmission rod, hopper, and installation of pills needed tablet press punching die with 75% ethanol solution one by one to wipe clean.

Open the door panel at the lower left side of the automatic tablet press and remove the block.

Two, the installation of the mold

Align the middle die of rotary press with the middle die hole and lay it flat. At this point, the bat through the punch hole, with a hammer gently knocked into the die, and the die plane is not higher than the turntable plane is qualified, and then the top wire in the die into and fixed.

3. Installation of tablet machine mold insert plate, copper ring, scraper, guide and tablet outlet

Insert the board into the correct position and tighten the screws. Connect the copper ring with the scraper, push it into the turntable, and fix the scraper in the correct position with hexagonal screws. Principle of installation and removal of copper ring and scraper: install and remove both at the same time. Attention should be paid to the installation of the guide: the guide should be higher than the lower surface of the head, and the height should be 1/2 of the thickness of the tablet. Then install the piece mouth, can not contact with the turntable, so as not to produce friction.

Iv. Installation of the lower punching rod of the tablet rotary tablet press

Apply lubricating oil to the lower punching rod of the automatic rotary tablet press, align with the lower punching die hole and push it into the hole (push method: hold the lower end with the palm of the right hand and gently push it up, other actions may cause injury). After installing the punching rod in turn, install the stopper. Then manually turn the car for 2-5 weeks, no abnormal sound is qualified.
