The Difference Between Vertical Cartoning Packing Machine And Horizontal Cartoning Packing Machine

The Difference Between Vertical Cartoning Packing Machine And Horizontal Cartoning Packing Machine

In the types of cartoning packing machines, in general, one is called semi-automatic cartoning packing machine that is assisted by manpower to move, and the other is called fully automatic cartoning packing machine that can move as long as there are materials. The box machine can also be connected with the automatic packaging machine and other equipment to form a production line. Nowadays, there are many types of automatic cartoning packing machines on the market, and the functions are also different. According to different structures, it can be divided into vertical automatic cartoning packing machine and horizontal cartoning packing machine.

The vertical automatic cartoning packing machine can pack different products, such as scattered screws, special-shaped hardware accessories, car light bulbs, or liquid bag products, and so on.

The whole process of packaging and forming of the vertical cartoning packing machine can be roughly divided into four stages: unboxing, opening, filling, and closing. The action of lowering the box is usually to suck a carton from the feeding port of the carton by a suction cup, go down to the main line of cartoning, fix the carton by a guide rail and open the carton with a push plate, at the same time there will be two The forward-moving catch rises from below and snaps the sides of the carton from front to back, allowing the box to open at right angles and move forward to the filling area. After filling in the loading area, the mechanism of the machine will fold the ears into the left and right guide rails, and then perform the closing action. The mechanism before closing the lid will first bend the tongue of the carton, and then a push plate pushes the lid to bend, so that the tongue is inserted into the box and the lock is fastened. The action of closing the lid is a key action, and the quality of the completion has a lot to do with the structure of the carton and the accuracy of machine adjustment.

The entire process of packaging and forming of the horizontal cartoning packing machine is also divided into four stages: unboxing, opening, filling, and closing. However, the way it packs boxes is different from that of vertical cartoning. In vertical cartoning, objects are generally fed from top to bottom or topped from bottom to top, while horizontal cartoning packing machines generally use cartons lying down. , The product is pushed into the carton from the side. This method requires the product to be relatively regular and easy to push. Such as mask, food, daily necessities and other multi-purpose boxes, the products are output horizontally by the conveyor belt. The vertical cartoning packing machine products are output vertically by the conveyor belt.

The choice of the two cartoning packing machines mainly depends on the type of your product.
