The Difference Between Vertical And Horizontal Cartoning Packing Machines

The Difference Between Vertical And Horizontal Cartoning Packing Machines

Among the types of cartoning packing machines, in general, one is a semi-automatic cartoning packing machine with manual assistance to carry out the movement, and the other is a fully automatic cartoning packing machine that can move as long as there is material, which can also be connected to a fully automatic packaging machine and other machines to form a production line. Nowadays, there are many different types of automatic cartoning packing machines on the sales market, and all of them have different functions. According to their construction, they can be divided into vertical automatic cartoning packing machines and horizontal cartoning packing machines.

Vertical automatic cartoning packing machines are able to carton different products, such as loose screws, shaped hardware, car bulbs, or liquid bagged products, etc.

The entire packaging process of a vertical cartoning packing machine can be roughly divided into four stages: lowering, opening, filling and closing the lid. The lowering action usually consists of a suction cup picking up a carton from the carton inlet, moving down to the main line of the carton loading, held in place by a guide bay and opened by a pusher plate, while two forward-moving bays rise up from below, catching the sides of the carton from front to back, opening the carton at right angles and moving forward to the filling area. After the filling area has been filled, the machine mechanism folds the ears into the left and right rails before the lid is closed. Before closing the lid, the mechanism bends the latch of the box and then a push plate pushes the lid to bend, inserting the latch into the box and fastening the latch. The lid closing action is a key action and its completion is highly dependent on the structure of the carton and the accuracy of the machine adjustment.

The horizontal cartoning packing machine is also divided into four stages: lowering the box, opening, filling and closing the lid. However, the way in which the carton is loaded is different from that of the vertical cartoning packing machine. The general situation of vertical cartoning is that the object is loaded from the top to the bottom or from the bottom to the top, while the horizontal cartoning packing machine generally has the carton lying down and the product is pushed into the carton from the side, which requires the product to be more regular and convenient to push. This way the product is required to be more regular and easy to push. This type of cartoning is used for mask, food and daily necessities, and the product is output horizontally by the conveyor belt. Vertical cartoning packing machines, on the other hand, are designed for vertical output by a conveyor belt.

The choice between the two types of cartoning packing machine depends on the type of product you have.
