Parameter Setting Factors For Capsule Counting Machines

Parameter Setting Factors For Capsule Counting Machines

① The setting size of the silo door has a great influence on the separation state of the material on the vibrating plate. The material flows out too fast if the gate is too big. Too small precision of capsule counting machine will affect the counting speed.

② Set the vibration frequency of the three-stage vibration plate. Set too fast, the material can not be effectively separated will affect the counting accuracy - too slow and affect the production speed.

③Set the product length and small parameters. The appearance size of the product is directly related to the luminous time and shade time of the infrared channel of the detection channel. The light-up time is the time between grains. The shorter the light-up time, the higher the resolution. The shading time depends on the external dimensions of the product. If the shading time is set too long, it will produce fewer counts. Setting the shading time too short will make the counter indistinguishable and culling will affect the counting speed.

④ Set the capsule counting machine projected value. The predicted number is such that the machine will continue to count tablets after the falling shroud finishes counting the bottle and replacing the bottle to increase throughput. After testing the first drug, all the drugs will fall into the detection channel, the memory cap will stop them and the empty bottle will reach the falling grain guard and the pre-counted drug will fall into the bottle. Too small a parameter setting will affect the counting speed, while too large a value will affect the counting accuracy.

⑤ Set the capsule counting machine counting speed. If the parameter is set too small, the products will be fully separated on the vibrating plate, which is good for counting accuracy. However, it is not favorable to increase the production speed. If the setting is too large, the products will not be separated on the vibration plate, which will seriously affect the accuracy of counting.

⑥ Setting of separation speed. Separation speed is the speed of separation between the last product of the previous bottle of intoxicating liquor and the product of the next * grain. Separation speed is too fast - the memory baffle will not be able to separate the product between the last bottle and the next bottle - more or less resulting in a - separation speed too slow and affecting the production speed!

Factors that reduce the sensitivity of the capsule counting machine cylinder:

As the actuating element of the capsule counting machine, the speed of response directly affects the accuracy of counting. The main causes of reduced cylinder sensitivity are moisture content in the compressed air, non-cylinder-specific grease, impurities entering the cylinder, and wear and leakage of cylinder seals.
