Use And Maintenance Of Automatic Counting Machine

Use And Maintenance Of Automatic Counting Machine

Candy counting machine troubleshooting

1 Pill bottling machine plugging: stop the machine to remove debris or plugging, repeatedly blocked, it is necessary to adjust the track, so that the relative position of each part of the guide rail, the lead distance should be slightly larger than the diameter of the pill, but not too large.

2 Putting bottle: observe whether the time of putting bottle is accurate and whether the distance between bottle electromagnet and bottle is appropriate.

3 the police:

3.1 See if the empty bottle is enough;

3.2 Photoelectric head of automatic counting machine blow with ear ball or wipe the glass pieces on both sides of photoelectric head gently with cotton, writing brush and other soft objects;

3.3 Adjust the sensitivity voltage of automatic electronic tablet counting machine;

Accuracy of automatic pill counting machine:

4.1 In the counting process of one bottle more or one bottle less, timed bottle extraction is detected. If it is found that the error cause is generally the inaccurate distance between the photoelectric head and the side guide rail or the inaccurate distance between the photoelectric head and the flip plate.

4.2 The number of automatic pill bottling machine may be due to the large distance between the side guide plate baffle and the track; Buy a way to pollute the photoelectric head (rubbing); Unconsciously gets too low (tune up); The left and right positions of the photoelectric head are adjusted (typically to the right);

4.3 Stainless steel electronic counting machine sensitivity is too high, adjust the sensitivity (small);

4.4 Photoelectric head left and right position adjustment (generally left).
