Parameter Adjustment Of Rotary Tablet Press Machine

Parameter Adjustment Of Rotary Tablet Press Machine

Installation and adjustment of the feeder of the automatic tablet press: install the feeder on the feeder support frame, screw on the knurled screw, and then adjust the adjusting screw to make the gap between the feeder bottom of the automatic rotary tablet press and the working surface of the turntable 0.05 ~ 0.1 mm. Tighten the knurled screw, and then adjust the height of the powder scraper to make the bottom plane flush with the working surface of the turntable. Tighten the screws.

Tablet thickness (pressure) adjustment of automatic tablet rotary tablet press: the tablet thickness (pressure) adjustment is controlled by the adjusting handwheel installed on the left side of the front of the machine, and there is an indication mark on the side of the handwheel. When the hand wheel of the automatic tablet rotary tablet press rotates counterclockwise, the tablet thickness decreases (pressure increases), otherwise the tablet thickness increases (pressure decreases). When the filling amount is set, check the thickness and hardness of the tablet, and then make appropriate fine adjustment until it is qualified.

Adjustment of filling amount of tablet press: the filling adjustment is controlled by the adjusting hand wheel installed on the right side of the front of the machine. There is an indication mark on the side of the hand wheel. When the hand wheel rotates clockwise, the filling amount decreases, otherwise it increases. During adjustment, it should be noted that there are enough particles in the feeder, and the pressure should be adjusted to make the sheet have enough hardness for weighing.

Adjustment of powder conveying capacity of tablet rotary tablet press: when the filling capacity is adjusted properly, adjust the amount of particles. First loosen the screw on the side of the bucket frame, then rotate the adjusting screw on the bucket frame to adjust the distance between the hopper port and the working surface of the turntable. Generally, the distance is qualified if the accumulated amount of particles in the feeding port is not overflowed. After adjustment, tighten the screws.
