Aluminum plastic plate box machine is widely used in the current enterprise production, highly automated, intelligent, concise is the main trend of future development.

Operation procedure of blister plate packing machine:
1. Open the electric green indicator light on, forming up and heat seal two heating switch respectively to the "ON" position, the workbench first, the temperature controller controls the forming temperature, generally preset 90C ˚ and 100C ˚ respectively, the second temperature controller heat seal, temperature preset 120C ˚ -140C ˚, molding and heat seal temperature controller preset temperature, specific set as appropriate.

2. Put down the lead roll on the block, the heating plate temperature in place, and then open the host, plastic PVC first molding, molding bubble hole and hot sealing mold hole position, pay attention to the thermal sealing mold seat with the handle to press the aluminum foil, aluminum foil will drive to the cutting. Observe whether the plastic (PVC) shifts from left to right. If there is a bias, adjust the lead pressure roller seat to mobilize the lead direction.

3. If the aluminum foil packaging machine moves left and right, the rotary section roller seat hand wheel can be adjusted down. If the deviation adjustable box movement.

4. Hot seal stamping after normal moderate open the feeder gate, make drugs (tablets, sugar coating) amount into the feeding room, if there is a small missing can be artificial filling, filling primary considerations: roller pressure roll hand and hook aluminum foil, and forming bubble eye to the roller side, there is missing, do not barely fill again, fill hole, drugs is brought into, more serious affect synchronization, light in aluminum foil sealing sticky mold, to machine processing.

5. Due to the increase of the weight of the drug, the gradual change procedures of aluminum foil tension and the temperature of the machine are different, which may produce the molding and thermal seal dissynchronization phenomenon, advance or lag, it is necessary to check whether the plastic PVC and aluminum foil have Yin separation, and then use the on-machine fine tuning mechanism to adjust. The fine tuning mechanism is adjusted forward and backward by the adjustment distance or the box. So before the boot should be placed in a neutral position, can move forward and backward, also can use the front box to move adjustment, after the correct movement, the section to wait for more than a dozen versions after the correct, so when not finished, do not adjust to adjust.
6. The thermal sealing quality of plastic aluminum foil (the adhesion is uniform, firm and straight) is shown by the temperature or pressure, the smoothness of the mesh plate, if there is poor thermal sealing, generally appropriate temperature, generally appropriate temperature, slightly lower pressure, adjust the temperature, adjust the screw volume pressure.

7. Cut the offset, cut with the layout offset, stop the hand adjustment box movement, can be moved.

8. Aluminum and plastic packaging machine in daily operation knowledge, for operation work must understand the structure of the machine, by the cam drive shaft roller, up and down travel, cover template position fixed dead, bubble bad state, pay attention to the forming mold or hot sealing to the stop point, tightening column nut, do not pay attention to easy failure, the roof seat roller pin bite phenomenon, elimination method.
